Butterfly Valve Lug Type Lever Handle: Premium Flow Control Solution
Engineered for precision, ERA's Handle Type Butterfly Valve features a lightweight, corrosion-resistant polyvinyl chloride (PVC) body. Operated manually via a robust lever handle, it enables smooth quarter-turn operation for precise flow control. Key design elements include a rotating disc, choice of EPDM or Viton seals (for optimal chemical resistance), and a sturdy handle lock to secure positions. This Handle Type Butterfly Valve delivers zero-leakage performance and is ideal for low-pressure systems handling acids, alkalis, water, and compatible fluids. Available in sizes DN15-DN300 (½"–12"), ensuring broad application suitability.
Place of Origin: Made in China
Material:
Body: ERA Premium LEAD FREE UNPLASTICIZED Polyvinyl chloride (PVC-U）
Handle: ABS Rubber
Ring: EPDM
Seal: TPE
Inside Ball: PP
Packing Method: Carton
Color:
Body: White, dark grey, blue
Handle: Red, blue, green
Dimensions(mm): 2"- 8"
Manufacturing Standards:
BS (BS3505)
ANSI (ASTM F1970)
Approvals and certifications:
Certified by NSF 14 & 61
Certified by UPC
Certified by CE
Certified by WATERMARK
Meathod of Jointing:
Solvent cement joint with pipes
Threaded joint
Working Pressure: PN16
Working Temperature: 0-45 DEGREE
Key Applications of the Handle Type Butterfly Valve
Water Management: Potable water distribution (certifiable to NSF/ANSI 61), wastewater treatment, and irrigation systems.
Chemical Processing: Safe handling of corrosive fluids in chemical plants, laboratories, and PVC-lined pipelines.
HVAC & Industrial: Cooling circuits, air handling units, and industrial water networks.
Aquaculture & Agriculture: Fish farms, hydroponic systems, and fertilizer dosing applications.
| Test item | Test reqirements | Test frequency |
| Dimension | Connect end Dimension：（Top，Middle，end）by plug gauge or caliperThread：by gauge（as per the standard ） | Once per batch |
| Seat tightness test | 1 hour hydrostatic test (top seal, bottom seal, low pressure test) | Once per batch |
| Torque test | ACCORDING ISO8233 | Once per day |
| Life test | Tested according to ISO8659 and cycled 2500 times, the component has no leakage. During the test, the inside of the sample is filled with water, the outside is air, the internal pressure is the nominal pressure, and the test is conducted at room temperature at a flow rate of (1±0.2) m/s. | Once per day |
| Vicor softening temperature | ≥74℃ | Once per day |
| Oven test | Standard of ISO1452-4 | Once per day |
| Valve shell streght test | No leaking ,no break | Once per day |
| Appearance | Smooth, uniform colour, no defects such as cracks, bubbles, peeling, severe cold spots, obvious variegation, decomposition and discoloration | 100% test |
| Pressure test | Close and open pressure test（1/2" - 2" 6KG keep 15second，above 2" 8KGS keep 15 second） | 100% test |
Why Choose ERA's Handle Type Butterfly Valves?
Production Excellence
Advanced Fabrication: CNC-machined PVC components guarantee dimensional accuracy and leak-proof assembly.
Custom Solutions: Valves tailored to specific pressure ratings (PN6-PN16), end connections (flanged, wafer, threaded - including BS Butterfly Valve (Handle Type) flange standards), and seal materials.
Rapid Prototyping: 15-day lead time for bulk orders with no Minimum Order Quantity (MOQ) restrictions.
Rigorous Quality Control
Material Testing: Only ISO 9001 compliant, certifiable PVC raw materials with anti-UV stabilization are used.
Performance Checks: Every valve undergoes hydrostatic pressure tests (1.5x rated pressure) and torque validation for consistently smooth disc rotation.
Traceability: Batch-specific documentation provided for full quality assurance.
Unmatched Service & Support
Technical Support: On-demand access to CAD drawings, detailed installation guides, and comprehensive chemical compatibility charts.
Global Logistics: Efficient FOB Taizhou port shipping with real-time tracking for reliable delivery.
Warranty: Backed by a 2-year warranty and 24-hour response commitment for replacements.
Expert Selection Guide
Fluid Compatibility: EPDM seals recommended for water/alkalis.
Size & Pressure: Match valve DN size precisely to pipe diameter. Verify PN rating suitability (e.g., PN10 for 10-bar systems).
Handle Configuration:> Standard lever handle enables quick shutoff; gearbox handles available for high-torque applications.
Certifications: Specify NSF/ANSI 61 certification essential for potable water applications.
Installation: Install between flanges using appropriate gaskets; critical to ensure disc rotation direction aligns correctly with flow. The Lug Type lever handle design simplifies positioning.
Trusted by chemical plants and municipalities worldwide, ERA combines German-engineered tooling with cost-efficient, high-quality Chinese manufacturing. The Handle Type Butterfly Valve represents our commitment to durability, precision, and exceptional value. For applications demanding robust manual flow control, the Handle Type Butterfly Valve is the proven solution. Contact us for custom quotes!
